- NASBF Series Third-harmonic Generator 南澳電氣NASBF三倍頻感應耐壓發生器 產品簡介 南澳電氣NASBF三倍頻感應耐壓發生器是利用磁路的飽和特性，取出裝置中分量最大的三次諧波電壓，對感應線圈式的電氣產品進行匝間、段間、層間的倍頻、倍壓試驗，以考核被試品的絕緣耐壓水平。 南澳電氣NASBF三倍頻感應耐壓發生器產品別名 三倍頻發生器，感應電壓三倍頻發生器，三倍頻電源發生器，三倍頻變壓器試驗裝置，三倍頻感應耐壓發生器，三倍頻試驗變壓器，三倍頻試驗儀，三倍頻感應耐壓儀，電壓互感器倍頻交流耐壓試驗儀 產品特性 1、南澳電氣生產的NASBF系列三倍頻發生器操作簡單、性能可靠 2、能很好地滿足變壓器、互感器感應耐壓的測量需要 南澳電氣NASBF三倍頻感應耐壓發生器產品參數 輸入容量：5-200KVA 輸出容量：1-40KVA 輸入電壓：三相AC380V 輸出電壓：0～300V；0-500V;0-800V;0-1000V 輸入頻率： 50Hz 輸出頻率：150Hz 結 構：小于2000A為一體式或分體式，大于2000A為分體式。 Product introduction NASBF series third-harmonic generator is utilize the saturation characteristics of magnetic circuit, remove the maximum three harmonic voltage from the device, for the induction coil type electrical product, make a turn to turn, segment to segment, and level to level frequency doubling and voltage doubling testing, so as to check the insulation withstand voltage level. Also called name Third harmonic generator, inductive voltage third-harmonic generator, third-harmonic generator power supply generator, trial third harmonic transformer device, third-harmonic inductive withstand generator, third-harmonic trial generator, third-harmonic testing device, third-harmonic inductive withstand device, voltage transformer frequency doubling AC withstand testing device. The Characteristics of the products 1, NANAO Electrical produced NASBF series third-harmonic generator, simple to operate, with reliable performance 2, Satisfy the need of transformers and inductors inductive withstand. The parameters of the products Input Capacity :5-200KVA Output capacity :1-40KVA Input voltage: Three-phase AC380V Output voltage: 0 ~ 300V; 0-500V; 0-800V; 0-1000V Input Frequency: 50Hz Output frequency: 150Hz Structure: less than 2000A as a whole or split instruction, more than 2000A is split instruction .
