南澳電氣NAKFR全自動變壓器空載負載特性測試儀

這真不是您需要的產品？
品　　牌：
南澳電氣

直接提問 | 回首頁搜
出廠價：
0

主要規格：

用　　途：

NAKFR Transformer unloaded &loaded characteristic tester 南澳電氣NAKFR全自動變壓器空載負載特性測試儀產品簡介南澳電氣NAKFR全自動變壓器空載負載特性測試儀是專用于變壓器空載損耗、短路損耗、零序阻抗、短路阻抗的儀器，空載損耗和短路損耗是發電機、電動機、變壓器試驗的重要項目；根據GB1094.5-85和IEC14/268CD規定，短路阻抗的變化量是判斷變壓器繞組有無變形的唯一判據。南澳電氣NAKFR全自動變壓器空載負載特性測試儀電路設計精巧，思路獨特，使得其性能優越，功能強大，體積小，重量輕，現場使用極其方便。該儀器內部采用先進的多A/D同步交流采樣及數字信號處理技術，成功的解決了低功率因數測量及多路信號在市電條件下同步測量和計算的難題，和乘法器功率測量技術相比具有顯著的優越性，NAKFR變壓器空載負載特性測試儀操作簡單方便，數據準確可靠，可完全取代傳統儀表的測試方法，可顯示并記錄用戶關心的所有測量數據，可作為現場高精度交流指示儀表使用。使用南澳電氣NAKFR全自動變壓器空載負載特性測試儀大大提高工作效率，減輕勞動強度。南澳電氣NAKFR全自動變壓器空載負載特性測試儀產品別名變壓器空負載測試儀、變壓器空載及負載特性測試儀、變壓器損耗測試儀、變壓器空載負載測試儀南澳電氣NAKFR全自動變壓器空載負載特性測試儀產品特性 1、可測量各種類型的變壓器的空載電流、空載損耗、阻抗電壓、短路損耗。 2、電壓回路寬量限：最大測量電壓750V，不用切換檔位即可保證測量精度。不會因電壓檔位選錯而對儀器本身有所損壞。 3、大屏幕、高亮度的液晶顯示，全漢字菜單及操作提示實現友好的人機對話，操作更簡便。 4、用戶可將測試數據實時打印出來。 5、采用數字同步采樣技術，準確測量三相用電設備的電壓、電流、功率、等參數的真有效值，測量精度為0.2級。 6、NAKFR變壓器空載負載特性測試儀可取代九塊同等級的指針儀表，是傳統電量測試儀表的理想換代產品。南澳電氣NAKFR全自動變壓器空載負載特性測試儀產品參數 1、輸入特性：電壓測量范圍：0~750V 寬量限。電流測量范圍：0~100A 內部自動切換量程。 2、準確度：電壓、電流：±0.2% 功率：±0.2%（COSΦ＞0.1），±0.5%（0.02 ＜CosΦ＜0.1） 3、工作溫度：－10℃~ +40℃ 4、工作電源：交流160V~265V 5、絕緣：電壓、電流輸入端對機殼的絕緣電阻≥100M?。工作電源輸入端對外殼之間承受工頻2KV（有效值），歷時1分鐘實驗。 6、體積：45cm×30cm×21cm 7、重量：3Kg Product introduction NAKFR transformer unloaded &loaded characteristic tester is dedicated to the transformer unload loss,short-circuit loss , zero sequence impedance,short-circuit impedance of the instrument,unload loss and short-circuit losses are generators,motors,transformers trials important items; according to GB1094.5-85 and IEC14/268CD regulations,changes in the amount of short-circuit impedance transformer winding is to determine whether the deformation of the sole criterion.The instrument circuit design is exquisite,unique ideas,making its performance is superior,powerful,small size,light weight,extremely easy to use site.The internal instrument uses advanced multi-A / D Synchronous AC sampling and digital signal processing technology,the successful solution of the low power factor measurement and multi -channel signal in the city,under the conditions of simultaneous measurement and calculation of the problem, and the multiplier power measurement technology has significant advantages over,NAKFR transformer no-load load Tester easy operation , accurate and reliable data that can completely replace the traditional instrumentation of the test method,the user can display and record all measurement data concerned,can be used as on-site precision AC indicating instrument used. Use instrument can greatly improve efficiency, reduce labor intensity. Also called name Transformer unloaded &loaded characteristic tester, Transformer unloaded &loaded characteristic test device, transformer loss tester, transformer unloaded &loaded tester The Characteristics of the products 1,Measure the transformer load loss, load current, load loss, impedance voltage, zero sequence impedance, short-circuit impedance, voltage RMS, average voltage, current, power, power factor, frequency and other parameters. 2,All the data are in the same cycle synchronous measurement, ensure that the mains accurate measurement results under the conditions of rationality. 3,With automatic waveform distortion correction, voltage correction, current correction, temperature correction, without any manual calculations. 4,The instrument allows the measuring range can be measured directly, can be an external primary voltage transformer and current transformer if beyond the measuring range.. 5,Can be locked for transcribing data while storing and printing all measurements, the instrument does not power down memory built, long-term measurement data is saved and ready for inspection. 6,With large blue LCD screen, full English menu and operation prompt, easy and intuitive. 7,Power-fail protective calendar and clock function. The parameters of the products 1,Basic measurement accuracy: voltage, current: 0.2% ± 3 words 2,Power: 0.5 (cosφ> 0.1), 1.0 grade (0.01 3, the voltage measuring range: AC0 ~ 800V 4,The current measurement range: AC0 ~ 80A 5,The frequency range: 45 ~ 60Hz 6,Working temperature: -10 ℃ ~ 40 ℃ 7,Humidity: 10% ~ 85% 8,Storage temperature: -20 ℃ ~ 50 ℃ 9,Dimension : 370mm × 260mm × 160mm 10,Weight: 7kg (not including test line) Power supply: AC110V/115V/120V/127V/220V/230V/240V optional Input frequency: 50Hz/60Hz optional Note: The users can select the corresponding power which based on their local supply voltage and frequency, and we will confirm it before the delivery (or inform us that the goods will be used in which country advance)
